INTRODUCTION |
PARAMETERS |
| Item | Unit | Parameter |
|---|---|---|
| Max. load capacity | t | 230 |
| Telescopic boom | m | 75 |
| Number of axles | - | 5 |
| Max. hoist height | m | 114 |
| Max. load moment | kN·m | 7393 |
| Drive engine model | - | WP13 |
| Drive engine power | kW | 390 |
| Drive/Steering | - | 10×8×10 |
| Driving speed | km/h | 80 |
| Dead Weight in Travel State | kg | 60000 |
| Dimensions | mm | 15850×3000×3980 |
| Emission standard | - | EU Stage V |
