INTRODUCTION |
PARAMETERS |
| Item | Unit | Parameter |
|---|---|---|
| Max. load capacity | t | 250 |
| Telescopic boom | m | 88 |
| Number of axles | - | 5 |
| Max. hoist height | m | 115 |
| Max. load moment | kN·m | 6586 |
| Drive engine model | - | OM471LA.E5-1 |
| Drive engine power | kW | 390 |
| Drive/Steering | - | 10×8 |
| Driving speed | km/h | 60 |
| Dead Weight in Travel State | kg | 70800 |
| Dimensions | mm | 17280×3000×4050 |
| Emission standard | - | EU Stage V、EPA/CARB Tier 4 final |
