With high presure common-rall electronic injection engine that meets EU stage-V emision standards equipped, XE220 EN crawler excavatorachieves the best fuel injection control, improving combustion efficiency, saving energy and protecting environment. Equipped with a new largediameter mult -way control vave, the hydraulic system is quick and effcient intemal pressure loss of the channel is reduced due to the furtheroptimization of the valve element, so the excavator maneuverability and composite operation efficiency are improved.Centralized lubrication on lubrication points of the working device makes it easy for lubrication.
| Item |
Unit |
Parameter |
| Operating weight |
Kg |
23400 |
| Rated power |
kW/rpm |
129 |
| Engine model |
- |
Cummins B6.7 |
| Bucket capacity |
m³ |
1.05 |
| Emission standard |
- |
Euro V |
| Maximum torque/speed |
N.m |
881/1300 |
| Displacement |
L |
6.7 |
| Travel speed |
km/h |
5.4/3.5 |
| Swing speed |
r/min |
11.8 |
| Bucket digging force |
kN |
149 |
| Arm digging force |
kN |
111 |
