Optimization of the power matching betveen the main pump and the engine acheves a reducton of more than 7% in the comprehensive fuelconsumption for excavation operations. The new load hydrauic sensitive system is equipped with "eight-ton large-diameter main valves, with a 33.3%increase in diameter further reducing pressure loss and optimizing the handing of composite movements Optmized and upgraded slewing torqueincreased torque by 20%. The width of chassis is increased by 60mm, which strengthens and enlarges the chassis, and the solid chassis makes theexcavation more stable and the operation easier.
| Item |
Unit |
Parameter |
| Operating weight |
Kg |
5750 |
| Rated power |
kW/rpm |
35 |
| Engine model |
- |
Kubota V2607 |
| Bucket capacity |
m³ |
0.21 |
| Emission standard |
- |
National Stage III |
| Maximum torque/speed |
N.m |
171.5/1100-1500 |
| Displacement |
L |
2.615 |
| Travel speed |
km/h |
4.2/2.4 |
| Swing speed |
r/min |
10 |
| Bucket digging force |
kN |
48.3 |
| Arm digging force |
kN |
32.5 |
