PARAMETERS |
| Item | Unit | Parameter |
|---|---|---|
| Suction tank volume | m³ | 8.4 |
| Volume of clean water tank | m³ | 3.2 |
| Fan type | - | Three-stage centrifugal fan |
| Maximum fan vacuum rate | % | 80 |
| Maximum airflow of fan | m³/h | 13600 |
| Suction tube diameter | mm | 200 |
| Vertical suction depth | m | 20 |
| Horizontal suction distance | m | 100 |
| Maximum flow rate of the pump | - | 227 |
| Maximum pump pressure | MPa | 20 |
| Unclogging hose length | m | 150 |
| Sewage recycling | - | Optional |
| Sewage recirculation system flow | L/min | 550 |
| Sewage recycling filtration accuracy | um | 500 |
