Product Attributes |
Model No.: XN20
Origin: China
Certification: CE & ISO
Type: Crawler Excavator
Usage: GM Excavator
Bucket: Backhoe
Size: Small-Scale
Certification: ISO9001: 2000
Condition: New
System Pressure: 22MPa
Max. Digging Depth: 2150mm
Track Width: 230mm
Diesel Oil No.: -10-10
System Flow Rate: 48L
Engine No.: 15w-40
Boom Swing-left: 390mm
Boom Swing-right: 510mm
Max. Digging Height: 3275mm
Max. Dumping Height: 2310mm
Packaging & Delivery |
|
Selling Units |
Bag/Bags |
|
Package Type |
container |
Product Description |
| Model | XN20 |
| Operating Weight | 2000kg |
| Digging bucket capacity | 0.05cbm/500kg |
| Digging bucket width | 420mm, can add narrow bucket is 200mm |
| Engine | Yanmar (3TNV70-S) |
| Rated power | 10kw/2200/r/min |
| Displacement | 0.854L |
| Bore stroke | three cylinder, water cool |
| Main pump | Italy Walvoil |
| Pump flow | 17x2+14 L/Min |
| Hydraulic oil tank capacity | 15.3L |
| Engine oil tank capacity | 2.8(1.3)L |
| Diesel tank capacity | 19 L |
| Working pressure | 22MPa |
| Valve | Italy Walvoil |
| Displacement | 6.8ml/r |
| Swing motor | JAPAN NAICH |
| Traveling motor | SOUTH KOREA DONGHYUAN |
| OPERATING RANGE | |
| Max. Digging depth | 2150 mm |
| Max. Vertical digging depth | 1740 mm |
| Max. Digging height | 3275 mm |
| Max. Dumping height | 2310 mm |
| Max. Digging radius on ground | 3610 mm |
| Min. Rotation radius | 1580 mm |
| Max. Upgrade height of bulldozer blade | 275 mm |
| Max. Digging depth of bulldozer blade | 180 mm |
