Product Attributes |
Model No.: XN75B
Origin: China
Certification: ISO/CE
Type: Wheel Excavator
Usage: GM Excavator
Bucket: Backhoe
Transmission: Hydraulic Transmission
Bucket Capacity: 0.1~0.5m³
Size: Medium-Sized
Certification: ISO9001: 2000
Condition: New
Packaging & Delivery |
| Selling Units | Bag/Bags |
| Package Type | container |
Specification |
|
SPECIFICATION |
Unit |
|
|
Operating Weight |
6066kg |
|
|
Bucket capacity |
0.3m³ |
|
|
engine |
Model |
Yanmar 4TNV94L |
|
|
Displacement |
3.054L |
|
|
Rated power / Speed |
33.7kw/2100rpm |
|
|
Maximum torque |
193.2-210.6N.m/1260±100 rpm |
|
Speed/Digging force |
Max.travel speed |
28km/h |
|
|
Swing speed |
11rpm |
|
|
Max. Grade ability |
30° |
|
MIAN DIIMENSION |
UNIT |
|
|
Total length |
mm |
6066 |
|
Total Height |
mm |
2880 |
|
Counter weight turning radius |
mm |
1820 |
|
Hood Height |
mm |
2052 |
|
Counterweight Ground Clearance |
mm |
1040 |
|
Upper structure width |
mm |
1944 |
|
Cab Height |
mm |
2880 |
|
Total Tire Width |
mm |
2070 |
|
Minimum Ground Clearance |
mm |
380 |
|
Wheel Tread |
mm |
2400 |
|
Distance of swing center to rear wheel |
mm |
966 |
|
Front Extension |
mm |
668 |
|
Back Extension |
mm |
740 |
|
The Maximum Reduction Of The Dozer Blade |
mm |
70 |
|
Height Of Dozer Blade |
mm |
510 |
|
Maximum Lift Of Dozer |
mm |
377 |
|
Overall Width Of Blade |
mm |
2026 |
