High Reliability: The light aluminum alloy beam has high bending, torsion and fatigue resistance. The unique single-layer hose reel can effectively improve the hose life and reduce the maintenance strength.
Precise Operation: The telescopic drill boom is kept in parallel in all directions, and the positioning is fast and accurate. The square structure provides high strength and good shock absorption performance.
Stable Construction: The drilling system has anti-jamming, anti-idle-drilling and automatic withdraw functions, which can effectively improve the drilling efficiency and reduce the loss of drilling tools.
Compact Design: With compact structure, the whole machine is flexible and convenient for operation in narrow spaces.
Safety Protection: The hood of the whole machine adopts full cover structure to provide safe and reliable protection.
| Item |
Unit |
Parameter |
| Engine Brand |
/ |
玉柴 Yuchai |
| Engine Model |
/ |
YCF3075-480 |
| Engine Rated power |
kW |
55.8 |
| Engine Emission standard |
/ |
国四 China Stage IV |
| Rock drill Brand |
/ |
安百拓 / 蒙特贝 / XCMG Epiiroc/Montabert/XCMG |
| Rock drill Model |
/ |
18U/HC109/XHD20 |
| Rock drill Impact power |
kW |
18/18/20 |
| Drill boom Boom extension |
mm |
900 |
| Drill boom Feed extension |
mm |
1500 |
| Feed beam Total length |
mm |
4740/5400 |
| Feed beam Drill steel length |
mm |
3090/3700 |
| Feed beam Single-pass drilling depth |
mm |
2700/3400 |
| Water system Rated flow |
m³/hr |
5 |
| Water system Min. water inlet pressure |
bar |
2 |
| Air system Flow |
L/min |
700 |
| Air system Pressure |
bar |
8 |
| Electrical system Voltage |
V |
380 |
| Electrical system Frequency |
Hz |
50 |
| Electrical system Cable length |
m |
80 |
| Chassis Gradeability |
° |
20 |
| Chassis Traveling speed |
km/h |
10 |
| Dimensions Transport state |
mm |
10700×1300×2710 |
| Total operating weight |
t |
10 |
