High Reliability: The light aluminum alloy beam has high bending, torsion and fatigue resistance. The unique single-layer hose reel can effectively improve the hose life and reduce the maintenance strength.
Precise Operation: The drill boom structure is newly optimized and upgraded to get larger extension stroke and shorter retracted length.
Stable Construction: The drilling system has anti-jamming, anti-idle-drilling and automatic withdraw functions, which can effectively improve the drilling efficiency and reduce the loss of drilling tools.
Safety Protection: The full cover structure, top anti-skid design, and air spring assisted opening of left and right doors provide convenience for maintenance. The enclosed cab with cooling and heating A/C ensures low dust and noise.
Intelligent Control System: The whole machine is equipped with a fully electronic control system based on CAN bus, which is easy and fast to operate.
| Item |
Unit |
Parameter |
| Engine Brand |
/ |
Cummins |
| Engine Model |
/ |
B3.9CS4 130 |
| Engine Rated power |
kW |
96 |
| Engine Emission standard |
/ |
Euro Stage III/China Stage IV |
| Rock drill Brand |
/ |
Montabert/XCMG |
| Rock drill Model |
/ |
HC95SA/XHD20 |
| Rock drill Impact power |
kW |
21/20 |
| Drill boom Boom extension |
mm |
1450 |
| Drill boom Feed extension |
mm |
1250 |
| Feed beam Total length |
mm |
5380/5990 (Optional) |
| Feed beam Drill steel length |
mm |
3700/4310 (Optional) |
| Feed beam Single-pass drilling depth |
mm |
3400/4000 (Optional) |
| Water system Rated flow |
m³/h |
6 |
| Water system Min. water inlet pressure |
bar |
2 |
| Air system Flow |
L/min |
1150 |
| Air system Pressure |
bar |
10 |
| Electrical system Voltage |
V |
380 |
| Electrical system Frequency |
Hz |
50 |
| Electrical system Cable length |
m |
80 |
| Chassis Gradeability |
° |
14 |
| Chassis Traveling speed |
km/h |
15 |
| Dimensions Transport state |
mm |
12611×2000×2750 |
| Total operating weight |
t |
22.5 |
